    Industrial portable barcode thermal label printer

    Ask Lasest Price
    Brand Name : rCloud
    Model Number : RCT-4610
    Certification : CE
    Price : Negotiation
    Payment Terms : T/T, Western Union,Paypal, L/C, D/A, D/P
    Supply Ability : 1000pcs per month
    Delivery Time : 5-8 work days
    • Product Details
    • Company Profile

    Industrial portable barcode thermal label printer


    Industrial Portable BarcodeThermal Label Printer

    • Description


    Printing methodThermal-line dot method
    Print speedMax:250mm/s
    Paper width58-82mm
    Paper thickness58-200um
    Paper diameterMax 150mm/Min:18mm
    InterfaceUSBRS232LAN

    RCT-4610 is 3 inch kiosk thermal printer which is consist of thermal printer head ,cutter and control board.

    It is used for financial self-service terminals, communication self-service terminals, coupons self-service terminals, ticketing self-service terminals, power self-service terminals, medical self-service terminals, insurance self-service terminals,tax kiosks, self-service terminals such as kiosk terminal equipment, tanker, Queuing machines and so on.


    • Technical Parameters


    PrintingPrint methodThermal-line dot method
    Print speedMax:250mm/s
    Resolution203dpi(8dots/mm)
    Effective printing area80mm
    CharacterCharacter setASCII,GBK,BIG5 and so on
    Print font

    ASCII:(9*17,9*24,16*18,12*24)

    Chinese:(24*24)

    The characters number per line

    Font A(12*24):32

    Font B(9*17):42 GBK:16

    Paper Roll specificationPaper typeThermal paper roll
    Paper width58-82mm
    Paper thickness55-200μm
    Max paper roll diameter/paper roll inner diameterMax:150mm/Min:18mm
    Paper Feed methodAutomatic feeding (straight out)
    detectionHead temperature detectionThermistor
    No Paper detectionPhotoelectric detection
    Paper near end detectionPhotoelectric detection
    Black mark detectionPhotoelectric detection
    Seam Mark DetectionPhotoelectric detection
    platen open detection functionMechanical switch
    Baud rate9600bps-115200bps
    Instruction SetEPSON ESC/POS Instruction Set
    DriverWindows Driver
    InterfaceUSB,RS232,LAN
    Barcode1D codeUPCA,UPC-E,JAN13(EAN13),JAN8(EAN8),CODE39,ITF,CODABAR,CODE128,CODE93;
    2D codeQR code
    ReliabilityPrint Life100Km
    Cutter life

    >1000000cuts

    (When cutting paper with thickness greater than 0.1mm, 500000cuts)

    CutterAuto cutterSupport full cutter and half cutter simultaneously
    PowerinputDC24V±10%,≥2A

    Environmental

    conditions

    Operating temperature0°C~50°C
    Operating humidity20%RH ~85% RH
    Storage temperature-20°C~60°C
    Storage humidity5% ~90%RH
    Overall dimension (wide * deep * high)With presenter(paper roll diameter 150mm)114.8*157*234.3mm(without paper bezel)
    Without presenter(paper roll diameter 150mm)114.8*157*233.8(without paper bezel)
    Without presenter(paper roll diameter 80mm)114.8*83*170.3mm (without paper bezel)

    • Production Feature

    1.large motor design and unique buffer

    Stepper motor design, cutting paper thickness up to 0.2mm, support 150mm paper roll diameter, reduce supplies replacement times, and buffer device can effectively prevent printing compression.

    2.Narrow-flat design of paper-taking channel

    Paper channel narrow flat design can print 0.2mm thickness of consumables.
    3.Fast Print speed
    Depending on the different driving energy and thermal sensitivity of the use of the heat-sensitive paper can be set according to user requirements of different printing speed, up to 250mm/seconds of printing speed
    4.Easy to load paper structure
    Unique rubber roller and print head slide away from the design scheme, it is easy to clean the print head and fault removal
    5.Penetrating photoelectric detection
    Penetrating photoelectric detection can be used for label seam mark Detection

    6.Quick Elimination Card Cutter
    A variety modes of Quick Elimination Card knife
    7.unique paper near end detection
    Easy to adjust the amount of paper
    8.Strong overall structure
    With thick sheet metal design, the structure is firm and difficult to deform

    9.Good heat dissipation of the motor
    Fixed motor is metal, can quickly heat dissipation

    • Question

    QI: When will you make the delivery?
    A: The delivery will be within 3-20 working days according to the size and quantities of your order.

    QII: How does your factory do regarding quality control?
    A: Quality is priority.Gamet people always attach great importance to quality controlling from the beginning to end.

    QIII: Do you accept personal customization ?

    A : Yes we are professional manufacturer of hardware&software solution provider for gaming machine,Which are focus on R&D manufacturing and marketing Illuminated card reader,RFID card reader,Hybrid card reader and Player Tracking System for Global Gaming System.we have profession- al designer for your needs.
